Tarmac Guide to Sustainable Road Building
Sustainable road construction guide
With over 300 local authorities declaring a climate emergency in 2019 and actively committing to net zero targets, there is clearly a pressing need for more sustainable approaches to road building and highway maintenance.
There are many aspects to consider when building more sustainable roads, from using lower carbon materials, reducing waste during construction and incorporating more recycled content, to extending pavement life and reducing future maintenance requirements.
Tarmac's range of innovative materials and paving solutions improve sustainability and reduce both carbon emissions and wider environmental impact. They are all available right now to help meet climate change commitments.
We also offer the advice and technical support to help match the right solution to the scheme or the challenge being faced, through a network of Technical Product Support Managers.
1. Using lower carbon materials
Tarmac is working hard to encourage adoption of lower carbon asphalt and concrete technology. Progress has already been made with over 3 million tonnes of Tarmac warm mix asphalts being laid on UK roads since 2014, but more needs to be done.
According to a report by the All Party Parliamentary Group (APPG) on Highways, if all asphalt production in Great Britain was been switched to WMA, it would save around 61,000 tonnes of CO2 per year – the equivalent of cutting almost 300 million miles of car journeys.
In August 2021 National Highways officially requested that everyone involved in the construction and maintenance of the strategic road network, particularly designers and main contractors, use warm mix asphalts as their default surfacing material to help move towards its net zero objective.
Warm mix asphalts
What is warm mix asphalt?
ULTILOW warm mix asphalts are manufactured and supplied at lower temperatures than conventional hot mix asphalts. As a result, they offer significant reductions in carbon dioxide emissions and a range of site safety and productivity benefits and no compromise on performance.
Warm mix asphalts have been included Specification for Highway Works since July 2019.
How do warm mix asphalts make roads more sustainable?
Reduced carbon footprint - ULTILOW warm mix asphalts offer up to 15% reduction in carbon dioxide emissions and typically around 8-10%.
Raised productivity and reduced programme times - ULTILOW warm mix asphalts also offer proven gains in productivity, requiring less time to reach trafficking temperatures and allowing more work to be completed within a given operating window. National Highways estimates that an increase in shift outputs of 20% could be provided by using WMA on its network. The lower asphalt temperatures also reduce fumes and steam on site. This means better visibility and improved safety during night-time and winter working.
What else can I do to make my road more sustainable?
Warm mix asphalts can be combined with recycled and secondary materials like reclaimed asphalt planings (RAP), rubber from end of life tyres and secondary steel slag aggregate.
Find out how we calculate the carbon footprint of asphalt
Fast, sustainable, single layer resurfacing on a busy London road
of material saved
Driving efficiency and reducing carbon on on the A350
The scheme was completed seven days earlier than programmed, providing a saving on the overall cost of £70k, principally from traffic management, whilst allowing for 25% more work to be completed.
Lower carbon concretes
Concrete has supported the evolution of man for over 2000 years; its durability and resilience are evident across the globe. In many vital applications, there is currently no better performing construction material. Today, as our world is changing to respond to climate and environmental impacts, we need to evolve our thinking when it comes to construction specification.
Low carbon concrete design is already available and proven. In fact, today as standard, we can achieve up to 70% reduction in the embodied carbon of concrete compared to CEM I.
Tarmac already offer a range of lower carbon concretes as standard, using GGBS and other cement replacement technology. Lower carbon bespoke mixes are also available on request for the full range of highways applications.
2. Using more recycled content and working towards a circular economy
One of the benefits of asphalt as a surfacing material is that it is recyclable. Once an old road surface is planed out in can be used in the construction of new roads.
Tarmac are investing in a new generation of asphalt plants like our state-of-the-art Birmingham Asphalt Plant that can incorporate higher levels of RAP content into asphalt mixes, for improved sustainability.
We are also leading the way in materials innovation that incorporates other secondary materials like steel slag aggregate and rubber from end-of-life car tyres into asphalt mixes, while maintaining or even enhancing performance.
Using more recycled content - from road building
How can asphalt planings be recycled?
Asphalt is already one of the world's most recycled construction materials. Tarmac are investing in a new generation of asphalt plants that can incorporate higher levels of reclaimed asphalt planings (RAP) into asphalt mixes for improved sustainability. This includes our state-of-the-art Birmingham Asphalt Plant located next to the M6 and ideally placed to support the Midlands Engine for Growth and our Harper Lane Asphalt Plant in Hertfordshire, serving Greater London.
However planings can also be recycled by mobile plant. In a highly controlled process, RAP is crushed and screened for consistency, then combined with additional aggregate, foamed bitumen and a hydraulic cement or lime binder.
How does foam mix asphalt recycling technology make roads more sustainable?
Using proven foamed bitumen and cold paving technology, road arisings can be processed and used in sub-surface reconstruction. As a result, it offers savings in both transport and disposal costs. ULTIFOAM recycled foam mix asphalt can be used as base and binder course in both new road construction and road maintenance. It provides safe encapsulation of tar contaminated road planings that are excluded from hot mix asphalt recycling and would otherwise be considered a hazardous waste requiring costly, specialist disposal. It also offers major environmental benefits from reductions in the use of energy and primary aggregates. This allows local authorities to recycle asphalt planings from their road network and use them elsewhere in road reconstruction. This improves sustainability and reduces disposal costs.
What else can I do to make my road more sustainable?
Warm mix asphalts can be combined with recycled and secondary materials like end-of-life tyres.
Our transition to a circular economy
FIND OUT MORE
Read about Resource Efficiency on our sustainability report website
Using more recycled content - from other waste streams
What is rubber modified asphalt?
Tarmac’s Ultipave R and Rubber Modified Asphalts are warm mix stone mastic asphalt that incorporate recycled rubber from end-of life car tyres. This helps to recycle some of the 40 million waste tyres generated every year in the UK.
For major trunk roads and motorways, ULTIPAVE R is now available as a rubber modified thin surface system, with BBA HAPAS Clause 942 approval for use on the strategic road network.
How do rubber modified asphalts make roads more sustainable?
Tarmac’s Ultipave R and Rubber Modified Asphalt use warm mix asphalt technology to achieve a lower carbon footprint, typically 8% lower than the equivalent conventional SMA. The use of recycled rubber crumb in the mix helps to avoid export of waste car tyres, incorporating approximately 750 tyres per kilometre for a typical single lane road.
Examples of using rubber modified asphalts to make roads more sustainable
Using our innovative Rubber Modified Asphalt to resurface the A426 in Leicestershire enabled the rubber from around 3500 tyres to be recycled and saved 14 tonnes of CO2 emissions.
What else can I do to make my road more sustainable?
Rubber modified asphalts can be combined with recycled and secondary materials like RAP and steel slag aggregate for an even more sustainable solution.
How can using steel slag aggregate make roads more sustainable?
Steel Slag aggregate is a secondary aggregate produced by the steel industry. The shape, hardness and heat retaining properties of steel slag aggregate make it an ideal material for use in asphalt, enabling good compaction and delivering excellent durability. Tarmac source steel slag aggregate from our facility at the steel works in Port Talbot, South Wales and transport it by rail, helping to make it a very sustainable material for road building.
3. Using less material, avoiding waste and reducing transport emissions
Making more efficient use of materials
How do thin surface course asphalts help make roads more sustainable?
Using thin surface course materials can improve sustainability of road resurfacing. Inlays using high performance asphalts, can offer an alternative to full depth reconstruction. This helps to reduce the depth of plane out required, the volume of asphalt used and the associated emissions from inbound and outbound transportation required.
Balanced use of high PSV stone for road building
The high PSV stone used to surface roads is a valuable resource. Hardstone quarries naturally produce a range of aggregate sizes in certain proportions. Using more 6mm, 14mm and 20mm asphalts helps to balance out high demand for 10mm aggregate for use in stone mastic asphalts (SMA’s) and surface dressing. The larger stone the stone size, the less secondary crushing required and the less stone is lost to dust.
This makes use of 14mm and 20mm asphalt surface courses more sustainable choices, where appropriate, helping to achieve a long-term balance in supply and demand for high PSV stone. One option is Ultipave Single Layer, a BBA HAPAS accredited 20mm asphalt designed for deeper single layer road reconstruction.
Reducing wasted asphalt from highways maintenance
How can we reduce waste from highways maintenance?
Using exactly the right quantity of asphalt material and extending the workability of asphalt materials can help reduce wasted materials from pothole repairs and road reinstatements.
How do site mixed asphalts make roads more sustainable?
Our award winning Ultipatch Sitemix asphalts, developed specifically for use with mobile asphalt batching plants, provide exactly the right quantity of fresh site mixed asphalt. As a result, they help to reduce waste from highways maintenance operations for a more sustainable approach. This innovative product won Highways Industry Product of the Year at the Highways Awards 2018.
How can we make highways maintenance more sustainable?
Tarmac Contracting are now using logistics and business process optimisation (BPO) technology to make highways maintenance activities more sustainable. This technology allows accurate tracking of materials from the plant to the site and was used recently during the resurfacing of the Silverstone Motor Racing Circuit.
How does BPO technology help make road building more sustainable?
Carbon emissions are minimised by making sure that exactly the right quantity of asphalt is supplied to the site, avoiding over-production and wasted material. Excess vehicle emissions are reduced by minimising vehicle movements and waiting times. Making sure that materials arrive at the optimal paving temperature also helps improve compaction, finish and the quality of joints. This helps to extend pavement life and avoids future maintenance to reduce long term carbon emissions.
Carbon conscious programme delivery
The recent A11, Thetford to Attleborough scheme in Norfolk was delivered in a carbon conscious and sustainable way, with carbon emissions systematically calculated throughout the project delivery. A number of materials and contracting decisions were made to reduce carbon emissions. This included using a warm mix asphalt binder and surface course in place of conventional hot mix asphalt and increased reclaimed asphalt planings (RAP) content. This helped to offset any additional carbon emissions from the SAMI layer and still deliver a 14% reduction in CO2 emissions on materials. Further reductions in CO2 emissions were achieved by ‘back-hauling’ road planings for recycling at Tarmac’s plants, using empty asphalt trucks. This delivered a 46% reduction in transport emissions.
Total project saving of 1,154 tonnes of CO2 emissions, a 20% reduction compared to the original plan.
Extending the life of asphalt overlays on concrete based roads
4. Building roads that last longer and extending pavement life
Making the right choice of material is particularly important on challenging roads that are subject to repeated cracking because of underlying movement in the pavement. This can include evolved roads, roads in areas with clay soils subject to seasonal expansion and contraction and roads based on jointed concrete that can be subject to thermal and traffic induced movement.
By adopting a whole life approach and investing in better materials and highways engineers can break the cycle of repeated deterioration and running repairs which can be costly in terms of maintenance budgets and carbon emissions.
Improving durability and crack resistance
What makes asphalt more crack resistant?
Modern high-performance asphalts which have been developed specifically to offer enhanced resistance to reflective cracking and road surface deformation. These products include a high-performance Polymer Modified Binder and selected aggregates, to enhance deformation resistance, for a longer lasting surface.
How do polymer modified, crack resisting asphalts make roads more sustainable?
By extending pavement life, polymer modified, asphalts extend surfacing intervals and reduce the materials and operational emissions associated with maintenance interventions. As a result they help reduce whole life costs.
Using an asphalt SAMI (stress absorbing membrane interlayer) can also extend the life of asphalt overlays on concrete based roads.
Age defying asphalts
Tarmac are now working with key industry partners in a new generation of asphalts that show far less deterioration from oxidation and loss of volatile oils and also less cracking or deformation from the stresses generated by traffic loading.
Right first time - Ultimate Tarmac – using technology to optimise asphalt mix for the weather conditions
Getting paving right first time is essential to building sustainable roads. Tarmac is pioneering the use of technology that uses site specific data and our materials expertise to tailor the specified asphalt to best fit conditions whilst optimising the material workability. This improves compaction and finish to help roads last longer.
Making quieter, safer roads
Asphalt for quieter residential roads
Tarmac’s ULTIFLEX asphalt delivers a smooth, negative texture making it one of the quietest hard-wearing surfaces available. Perfect for residential streets. ULTIFLEX is also available as a warm mix asphalt with a reduced carbon footprint.
Cleaner air and reduced fumes
Improving air quality when resurfacing roads
Warm mix asphalts reduce site fumes by approximately 90%, improving air quality for site workers and helping to meet clean air targets.
Encouraging more sustainable forms of transport
Building brighter, safer cycleways
ULTICOLOUR coloured asphalts are helping to build the next generation of visually distinctive and safer cycleways to encourage more people to choose cycling as a regular means of transport. Delivering clear visual demarcation and a smooth, finish helps to enhance safety for cyclists and pedestrians.
Sustainable Rail Transport
With more than 60 rail-connected sites across the UK, Tarmac are one of the country’s biggest users of the rail freight network, transporting around nine million tonnes of materials every year. This extensive use of rail transport helps to avoid thousands of heavy goods vehicle journeys and eliminate the associated carbon emissions.
6. Tarmac’s commitment to sustainability
Our commitment to providing sustainable solutions is also demonstrated by our certification to BES 6001 the framework standard for Responsible Sourcing, across our entire product range at “Excellent” standard.
These certificated can be found on our website.
Sustainability is about securing long-term success for our business, customers and communities by continually improving environmental, social and economic performance throughout the whole life cycle of our products, services and solutions.
Calculating the CO2 footprint for a product not only provides a clear understanding of the products that are being used but also allows for carbon to be managed in the supply chain. It is also possible to compare alternative products and services, actively seek lower carbon alternatives and understand the impact of using recycled and secondary materials
Our solution guides encompass all parts of our business including Aggregates and Asphalt, Building Products, Cement, Lime and Powders and Ready Mixed Concrete and wider aspects of sustainable construction such as whole building approaches and sustainability certification schemes. The guides provide an improved understanding of how products and solutions we produce can be used to deliver a better, more sustainable built environment.
